These cables are designed from NEATEL to create high-speed 400G Ethernet links between network devices that have different port types. Specifically, they solve the compatibility issue of connecting a switch with a QSFP-DD port to a network card or another device with an OSFP port. They are plug-and-play, hot-pluggable, and built to MSA (Multi Source Agreement) standards, which helps ensure interoperability.

✔ Provide Professional Compatibility and Parameter Test Reports.
✔ Compliant with Hot Pluggable OSFP and QSFP-DD MSA Standard.
✔ Compliant with RoHS Environmental Standard (Lead-free).
✔ DDM(Digital Diagnostic Monitoring) Supported.
✔ 30-Day Free Return, 1-Year Free Replacement, 3-Year Warranty, Lifetime After-sales Technical Support.
✔ Data Rate: 400 Gigabits per second.
✔ Cable Type: Active Optical Cable (AOC). This type integrates transceivers directly into the cable ends, which simplifies deployment and offers longer reach than passive copper cables.
✔ Connectors: OSFP (Flat Top) on one end and QSFP-DD on the other.
✔ Power Consumption: Typically ≤10W per end.
✔ Key Features: Include support for Digital Diagnostic Monitoring (DDM/DOM), a minimum bend radius of 30mm to avoid damage, and an operating temperature range of 0 to 70°C.
✔ Compliance: They are generally compliant with IEEE 802.3bs, QSFP-DD MSA, and OSFP MSA standards.

Application

✔ Big AI Data Center Fiber Optic Netwoek Application;
✔ InfiniBand QDR, SDR, DDR;
✔ Servers, switches, storage and host card adapters.
