12 Cores Fiber Optic Distribution Box
Item Description
NEATEL's distribution box terminates outside optical cables with up to 12 fibers; it allocates 12 adapters for connecting with max 12 drop cable pigtails, it is also suitable for using with mini splitters. The box works under both indoor and outdoor environments. It is a perfect cost-effective solution-provider in the FTTH networks.
Features and Applications
Features


1) ABS material used ensures the body strong and light;

2) Protection Level: IP55;

3) Water-proof design for outdoor uses, lock provided for extra security;

4) Easy installations: Ready for wall mount – installation kit provided;

5) Adjustable adapter slotused – to suit different size pigtails;

6) Space saving! Double-layer design for easier installation and maintenance;

7) Lower layer for splicing, also suitable for mini splitters;

8) Upper layer for adapters, connectors and fiber distribution;

9) Cable fixing units provided for fixing the outdoor optical cable;

10) Both cable glands and tie-wraps accessible;

11) Pre-connectorized cables supported (pre-connected with fast-connectors);

12) Bend radius protected and cable routing paths provided.

Technical Parameter
Dimensions and Capability

Dimensions (W*H*D) 260mm*220mm*95mm
Adapter Capacity 12 x SC/FC simplex adapters or LC duplex adapters
Number of Cable Entrance/Exit 2/12 simplex drop cables (Pre-connectorized cables supported)
Optional Accessories Adapters, Pigtails, Heat Shrink Tubes
Weight 0.75 KG
