The equipment designed from NEATEL is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, and distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.

✅ Water-proof design with IP-68 Protection level;

✅ Integrated with flap-up splice trays and adaptor holder;

✅ Impact test:IK10,Pull Force:1000N,Full rugged design;

✅ All stainless metal plate,anti-rust bolts and nuts;

✅ Fiber bend radius control more than 40mm;

✅ Suitable for the fusion splice or mechanical splice;

✅ 1:8 or 1:16 PLC Splitter can be installed in each splice tray as option;

✅ 1 mid-span cable entrance (10-18mm) for uncut cable and 2 Mechanical glands for distribution cable (8-18mm);

✅ 3mm glands for flat drop cable (defaulted) , 7mm or 5mm glands for round drop cable (optional);

✅ 24 adaptors for drop cable patching.
